Flowair ELiS B
Commercial Air Curtain
The Flowair ELiS B is a recessed air curtain engineered to deliver effective climate separation while remaining completely hidden within the ceiling plane. It creates a controlled air barrier that limits heat loss in winter and prevents warm external air entering air-conditioned spaces in summer, ideal for high-standard interiors where discretion matters.
KEY FEATURES
Recessed ceiling mount
Up to 6,600 m3/h airflow
Ambient, electric, or LPHW
1m, 1.5m, and 2m lengths
T-Box touchscreen control
Quiet operation
PRODUCT OVERVIEW
Invisible Performance, Hidden in the Ceiling
The Flowair ELiS B is designed for seamless integration into suspended ceilings without the need for additional service cut-outs. Unlike surface-mounted air curtains, it sits entirely within the ceiling plane. Only the anodised aluminium inlet and outlet profiles are visible from below, blending naturally with the interior.
This makes the ELiS B the ideal choice for architects, interior designers, and facilities managers working on premium commercial spaces where both performance and aesthetics are non-negotiable. The unit can be supplied in a wider range of colours on request, making it easier to match architectural and interior design schemes.
Despite its discreet appearance, the ELiS B delivers serious air barrier performance with a maximum effective range of up to 5 metres and airflow rates ranging from 2,200 m³/h to 6,600 m³/h depending on model and configuration. Its construction combines durable aluminium, plastic, and steel for reliable long-term operation.
CONFIGURATIONS
Flexible Heating Options & Sizes
The Flowair ELiS B is available in three standard lengths and three heating configurations, allowing precise matching to your entrance dimensions, usage levels, and building services infrastructure.
​
-
LPHW (Low Pressure Hot Water) heat exchanger, connects to existing wet heating systems for efficient, centralised heat delivery
-
Electric heating elements, a self-contained option requiring no water pipework, ideal for retrofit or standalone applications
-
Ambient (unheated), for climate-controlled buildings where door separation without additional heating is the priority
-
Available in 1m, 1.5m, and 2m lengths to suit standard commercial doorways
-
Effective door coverage up to 5 metres in height
KEY BENEFITS
Why Choose the ELiS B?
The ELiS B combines invisible recessed installation with powerful air barrier performance and intelligent control system integration.
Completely Recessed
Mounts entirely within the suspended ceiling with no visible unit. Only the slim anodised aluminium inlet and outlet profiles are seen from below. No additional cut-outs required.
Powerful Airflow
Delivers 2,200–6,600 m³/h of airflow with an effective range of up to 5 metres, providing reliable climate separation even for larger commercial entrances.
Exceptionally Quiet
Compact structure and quiet operation make it well suited for high-standard representative spaces where noise would be disruptive, such as retail, restaurants, showrooms, and galleries.
Intelligent Controle
DRV control module as standard with T-Box integration for centralised multi-unit management, demand-based operation, and BMS connectivity for facility-wide control.
Built to Last
Constructed from durable aluminium, plastic, and steel for reliable long-term operation. Anodised aluminium profiles with optional custom colours to match interior finishes.
Energy Efficient
Maintains a stable indoor climate that reduces the load on heating and cooling systems. Demand-based operation via the FLOWAIR SYSTEM ensures energy is only used when needed.
APPLICATIONS
Ideal For These Environments
The recessed ELiS B is designed for premium commercial and public spaces where visible equipment is undesirable.
Retail
High-street and boutique entrances
Offices
Reception areas and lobby entrances
Restaurants
Dining entrances and terraces
Pharmacies
Quiet, clean entrance control
Hotels
Guest-facing lobby entrances
Showrooms
Vehicle and product displays
Museums & Galleries
Climate sensitive public spaces
Shopping Centres
Main entrances and malls
